Brand Siemens
Series S7-1200
SKU SIEMENS-S7-1200-VFD-KIT-01
Price From $1,685.60
Siemens
Siemens S7-1200 PLC + V20 VFD Dual-Motor Hands-On Training Kit
Dual-motor VFD trainer with CPU 1215C, V20 inverter, and 4G IoT module for advanced industrial automation practice.
- Siemens S7-1200 CPU 1215C (6ES7215-1AG40-0XB0)
- KTP400 Basic HMI and SINAMICS V20 VFD
- CB1241 RS485 module and SM1222 digital output module
- Dual three-phase motors with encoder for closed-loop control
- Industrial switch and 4G IoT module (KIT-01)
- Analog speed control (0-10V / 0-20mA) and communication-based VFD control
- PROFINET (dual ports), MODBUS RTU, USS protocol support
- Pre-wired in rugged portable case
Who Is This For
Advanced vocational schools, university automation labs, and enterprise training centers teaching multi-motor control, industrial communication, and IoT-based remote monitoring.
Technical Specifications
| PLC Model | Siemens S7-1200 CPU 1215C (6ES7215-1AG40-0XB0) |
|---|---|
| HMI | Siemens KTP400 Basic |
| VFD | SINAMICS V20 |
| Comm Modules | CB1241 RS485 |
| Output Module | SM1222 |
| Motors | Dual three-phase motors with encoder |
| IoT | 4G IoT module (KIT-01 only) |
| Communication | PROFINET (dual), MODBUS RTU, USS |
| Speed Control | 0-10V / 0-20mA analog + communication-based |
| Dimensions | 500 x 340 x 200 mm |
| Weight | 10.0-12.5 kg |
| Configurations | KIT-01 ($2,050.60), KIT-02 ($1,713.00), KIT-03 ($1,685.60) |
| Software | TIA Portal V20 (not included) |
Complete hardware setup, documentation, and support for classroom or training-room use.
More Buying Information
Use these pages to compare related products, shipping details, and customization options.
Frequently Asked Questions
Common questions about this product.
What is the difference between KIT-01, KIT-02, and KIT-03?
KIT-01 ($2,050.60) includes dual motors, industrial switch, and 4G IoT module. KIT-02 ($1,713.00) includes dual motors and encoder without the IoT module. KIT-03 ($1,685.60) is a single-motor configuration.
How is this different from the single-motor S7-1200 VFD kit?
This kit uses the more powerful CPU 1215C (instead of 1212C), adds a second motor for dual-motor control exercises, includes a CB1241 RS485 module for additional communication protocols, and offers an optional 4G IoT module for remote monitoring.
What communication protocols can I practice?
PROFINET (Ethernet protocol) via dual ports, MODBUS RTU and Siemens USS protocol via the CB1241 RS485 interface.
